ERA Piping Systems, PVC Pipe Fitting ,Cross, US4C01, Schedule 40 (ASTM D2466) , NSF-pw & UPC
System：
SCH40 pressure fitting is easy to install and has better sound deadening qualities than PVC DWV fittings.
Installation requires the use of primer and solvent cement. For pressure applications, sharply angled pressure fittings must be used.
Scope：
Never test with or transport/store compressed air or gas in PVC pipe or fittings. Doing so can result in explosive failures and cause severe injury or death.
Polyvinyl chloride (PVC) is one of the most broadly used thermoplastic materials, common to many industries.
Specification：
This specification covers poly(vinyl chloride) (PVC) Schedule 40 pipe fittings made from four PVC plastic compounds and intended for use with Iron Pipe Size (IPS) outside-diameter plastic pipe.
Fittings fabricated by welding are not included in this specification. Included are requirements for materials, workmanship, dimensions, and burst pressure.
| Model Number | US4C01 | Material | PVC |
| Description | CROSS | Size | 1/2''-4'' |
| Standard | SCH40 | Color | Grey WHITE BLACK |
| Working Pressure | PN10 ,10Bar, 1.0Mpa | Temperature | Max 60°C / 140°F |
| Connection | SOCKET OR THREAD | Certificate | NSF UPC |
Main Products：
1. It has good tensile and compressive strength: but its flexibility is not as good as other plastic pipes.
2. Small fluid resistance: The pipe wall of PVC-U pipe is very smooth and has very little resistance to fluid. Its roughness coefficient is only 0.009. Its water transport capacity can be 20% higher than that of cast iron pipes of the same diameter and 40% higher than that of concrete pipes. %.
3. Excellent corrosion resistance and chemical resistance: PVC-U pipes have excellent acid resistance, alkali resistance, corrosion resistance, and are not affected by moisture and soil pH. No anti-corrosion treatment is required when laying pipes.
4. Good water tightness: PVC-U pipes have good water tightness regardless of whether they are connected by bonding or rubber rings.
5. Anti-gnawing: PVC-U pipe is not a nutrient source, so it will not be eroded by rodents. According to tests conducted by the American Sanitation Foundation in Michigan, rats will not chew PVCU pipes.
6. Performance test: curing time, shrinkage rate, splitting strength, tensile properties, peel strength, thermal stability, applicable period, release of harmful substances during storage period.
PVC 4-way tee fittings are commonly used in water supply systems to facilitate branching of pipes in multiple directions. These fittings allow for the connection of four pipes at right angles, enabling the creation of complex plumbing configurations. They are typically made of PVC material, which provides excellent corrosion resistance and durability. When selecting PVC 4-way tee fittings for water supply pipes, it's essential to ensure that they meet relevant industry standards and are compatible with the specific pipe size and pressure requirements of the application.
