Scope：

Joints and fittings for use with unplasticized PVC pressure pipes. Injection moulded unplasticized PVC fittings for solvent welding for use with pressure pipes, including potable water supply

Specification：

Convenient and reliable installation, low construction expenses

Excellent heat-insulation property from minimum thermal conductivity

Proven physiological harmlessness

Universal use

Fields of application:

Piping networks for irrigation, normal water transport for industry.

Referenced Standards：BS 1452-3



PVC-U pipe has strong corrosion resistance, easy bonding, low price and hard texture. However, due to the leakage of PVC-U monomer and additives, it is only suitable for the water supply system where the conveying temperature does not exceed 45℃. Plastic piping is used for drainage, wastewater, chemicals, heating and cooling fluids, food, ultra-pure liquids, mud, gas, compressed air and vacuum system applications.

Pvc-o pipe, Chinese name biaxial oriented PVC, is the latest form of evolution of PVC pipe, through the special orientation processing technology to manufacture the pipe, the PVC-U pipe produced by extrusion method for axial stretching and radial stretching, so that the PVC long chain molecules in the pipe in the biaxial arrangement, A new PVC pipe with high strength, high toughness, high impact and fatigue resistance was obtained.

Advantages of pipes：
1. It has good tensile and compressive strength: but its flexibility is not as good as other plastic pipes.
2. Small fluid resistance: The pipe wall of PVC-U pipe is very smooth and has very little resistance to fluid. Its roughness coefficient is only 0.009. Its water delivery capacity can be 20% higher than that of cast iron pipes of the same diameter and 40% higher than that of concrete pipes. %.
3. Excellent corrosion resistance and chemical resistance: PVC-U pipes have excellent acid resistance, alkali resistance, corrosion resistance, and are not affected by moisture and soil pH. No anti-corrosion treatment is required when laying pipes.
4. Good water tightness: PVC-U pipes have good water tightness regardless of whether they are connected by bonding or rubber rings.
5. Anti-gnawing: PVC-U pipe is not a nutrient source, so it will not be eroded by rodents. According to tests conducted by the National Sanitation Foundation in Michigan, rats will not bite PVC-U pipes.
6. Performance test: curing time, shrinkage rate, splitting strength, tensile properties, peel strength, thermal stability, potency period, storage period, release of harmful substances.
