System：CPVC Copper Tube Size (CTS) Hot and Cold Domestic Water Distribution

Specification：

It is lightweight, easy to assemble and install. Job-site erection of a leakproof joint can be made in only a minute with solvent cement, or by threading.

Technology：In July,2014, Yonggao Research Institue was officially put into use with total investment of 35 million RMB, six-storey design of over 5000 square meters. Now Yonggao has set up independent research system in joint with Shanghai, Anhui,Guangdong ,and Tianjin branches.

ERA R&D department is the one of the strongest resesrch team naitionwide with the latest national laboratory equipment and high-tech talent.

★ Pipe :CPVC is mainly used for the production of plate, bar, pipe transportation of hot water and corrosive medium, can maintain enough strength when not more than 100 ℃, and can be used for a long time under high internal pressure. The weight of CPVC is 1/6 of copper, 1/5 of steel, and has very low thermal conductivity, therefore, the pipe made of CPVC, light weight, good thermal insulation performance, no insulation.

★ CPVC tube can be used as factory hot sewage pipe, electroplating solution pipe, thermochemical agent conveying pipe, chlorine alkali plant wet chlorine gas conveying pipe.

★ Injection molding parts: CPVC resin can produce water supply pipe fittings, filter materials, dehydrators, but also can produce electrical and electronic parts. Such as wire groove, conductor protective layer, electric switch, fuse protective cover, cable insulation material.

★ Calendering sheet: can be used to manufacture chemical resistant, corrosion resistant chemical equipment, such as reactors, valves, electrolytic cells, etc.

★ Composite material: CPVC and some inorganic or organic fibers composed of CPVC composite material has good impact resistance, heat resistance is better than other resin composite material, can be made into plate, pipe, corrugated plate, profile and so on.

★ CPVC can be used for the modification of chlorylon fiber: the washing and drying temperature of domestic chlorylon fiber shall not exceed 60 ℃, adding 30% CPVC when spinning chlorylon, can greatly improve the heat resistance of the product, the shrinkage rate from the original 50% to less than 10%.

★ Foaming material: the heat resistance of CPVC foaming material is better than that of PVC foaming material. High temperature shrinkage is quite small, can be used as hot water pipe, steam pipe insulation material. The retention of CPVC with chlorine content of more than 60% is quite good to the solvent, CPVC can be placed in the solvent that can produce gas when heated to foam, can get uniform, microporous foam gas, available boiling point of 50-160 ℃ hydrocarbons, ethers, aldehydes and other solvents as foaming agent.

★ Others, CPVC and thermoplastic or thermosetting plastic blend, can significantly improve the physical and mechanical properties of these materials, such as the heat resistance of products to improve.

★ CPVC with higher impact resistance and better transparency has been prepared by improving the production process abroad. This transparent material can be used in automobiles, optical discs, audio and video products, and has good economic benefits.
