Scope：ERA BRAND PVC-C has been designed for enhanced chemical resistance and exceptional temperature stability. Metric PVC-C systems are in use wherever aggressive media such as mixed acid waste or alkalis at a high temperature are transported.

Specification：CPVC has an operational temperature range of 0°C - 80°C (32°F - 176°F), which is suitable for high temperature environments. The excellent mechanical characteristics, high tensile strength, stiffness, and impact strength are evident even at increased temperatures.

Fields of application：1、Transport of wide range of chemicals and corrosive fluids in the industry.

                                     2、Chemical Applications

                                     3、Building Technology

1) CPVC pipe has high heat resistance and can be applied to hot water and chemical thermal fluid transportation.

(2) CPVC pipe has excellent corrosion resistance, acid, alkali, salt and other chemical solvent corrosion, grease does not crack.

(3) CPVC pipe has good insulation, galvanic corrosion resistance, low heat transfer, and can be applied to high-voltage heat-resistant electric power pipe.

(4) The product has obtained the NSF National Health Association certification

Characteristic：
1. Material properties
PVC-C pipe
PVC-C power pipes are made of PVC-C resin with excellent heat resistance and insulation properties as the main material. PVC-C products are currently recognized as green and environmentally friendly products, and their excellent physical and chemical properties are increasingly valued by the industry.
PVC-C electric power pipe is a hard straight solid wall pipe with smooth inner and outer walls and an orange-red color, which is bright and eye-catching.
2. Heat resistance
The heat resistance temperature of PVC-C power pipe is 15°C higher than that of ordinary UPVC double-wall corrugated pipe. It can maintain no deformation in an environment below 105°C and has sufficient strength.
3. Insulation performance
PVC-C power pipe can withstand high voltages of more than 30,000 volts.
4. Compression resistance
PVC-C power pipe has been modified with materials, and the ring stiffness of the product reaches 1Okpa, which is significantly higher than the regulations of the relevant national departments for buried plastic pipes, whose ring stiffness should be above 8kpa.
5. High impact strength
PVC-C power pipe can withstand the impact of a 1kg weight and a height of 2m at a temperature of 0°C, which fully reflects the low-temperature impact performance of the material and is fully applicable to the requirements of construction environmental conditions.
6. Flame retardant performance
Both PVC and PVC-C materials have good flame retardant properties and can be extinguished immediately after leaving the fire. Especially PVC-C material, because its chlorine content is significantly higher than PVC, the flame retardancy and smoke density index are significantly improved.
7. Installation performance
PVC-C power pipe is light in weight, high in strength, and has a simple construction and laying method. It can be excavated and buried at night, backfilled on the road surface, and can be opened to traffic during the day. It adopts elastic sealing rubber ring socket connection, which is easy and fast to install and connect, and has good connection sealing performance. It is good and can prevent the leakage of groundwater and effectively protect the safety of power cables.
8. Long service life
PVC-C power pipe material is corrosion-resistant, anti-aging, and has a service life of more than 50 years.
